2235QTIMAX-2 1/2” Square Drive, 2” Ext Anvil, Friction Ring Ingersoll Rand 1350 ft-lbs Pistol Grip Air Impact Wrench. Actuation/Throttle Type/Switch Type: Trigger Air Consumption @ Load (cfm): 24 cfm Air Consumption @ Load (l/min): 680
The 2235QTIMAX-2 1/2” Square Drive, 2” Ext Anvil, Friction Ring Ingersoll Rand 1350 ft-lbs Pistol Grip Air Impact Wrench is lightweight, durable and versatile. Itll withstand anything you throw at it and still deliver the same quality output every time. And with a two-year warranty, you never have to worry about manufacturing defects slowing you down.
The high torque output of the powerful 7 vane motor is optimized to increase safety and control over the tool. 1,350 ft-lb nut-busting torque. Titanium hammer case is designed to be strong and durable, to protect the interior components of the air impact wrench. Impact-and-chemical-resistant housing and patented steel reinforced frame protects against repeated drops and exposure to shop fluids. Features a patented quiet tool technology reducing sound levels without compromising best-in-class power performance. The 2-inch extended anvil provides you with increased reach thats invaluable when working with deeper fasteners. A lightweight, balanced, air impact wrench that weighs just 4.6lbs. The 2235TiMAX Series comes with a two-year manufacturing warranty, so youre covered in case of any defects or serious issues. Optimized for the vehicle repair industry, heavy trucks, tire lanes, fleet maintenance, body shops, general industrial use, MRO, rail, heavy machinery, oil and gas, shipbuilding, and construction.
The 2235QTIMAX-2 1/2” Square Drive, 2” Ext Anvil, Friction Ring Ingersoll Rand 1350 ft-lbs Pistol Grip Air Impact Wrench is backed by a 2-year warranty for peace of mind.
| Part Number | 2235QTIMAX-2 |
|---|---|
| Actuation/Throttle/Switch | Trigger |
| Air Cons. @ Load (cfm) | 24 cfm |
| Air Cons. @ Load (l/min) | 680 l/min |
| Air Inlet | 1/4'' NPT |
| Air Pressure (PSI) | 90 PSI |
| Anvil Length | 2'' Extended |
| Average Air Cons. (cfm) | 6 cfm |
| Average Air Cons. (l/min) | 170 l/min |
| Blows per Min | 1220 BPM |
| Color | Grey |
| Configuration/Handle Type | Pistol Grip |
| Drive Size | 1/2'' |
| Drive Type | Square |
| Duty Rating | Maintenance Duty |
| End Plates | Aluminum with Steel Wear Plate |
| Exhaust Location | Bottom |
| Free Spd Sound Prssr/Pwr | 88.7 / 99.7 |
| Hammer Case | Titanium |
| Handle Material | Composite |
| Housing Material | Impact and Chemical-Resistant Composite Housing and Patented Steel Reinforced Frame |
| Impact Mechanism | Twin Hammer |
| Impact Sound Prss/Pwr Db(A) | 91.9 / 102.9 |
| Max Bolt Diameter | 0.75'' |
| Max Free Speed (rpm) | 8500RPM |
| Max Pressure | 6.2 bar |
| Max torque | 900 ft-lbs / 10798 in-lbs / 1220 Nm |
| Min. Hose Size | 3/8'' |
| Motor | Reverse Bias |
| Number of Power Settings | 4 |
| Nut-busting/Breakaway Trq | 1300 ft-lbs / 15604 in-lbs / 1763 Nm |
| Power Source | Air Powered |
| Pwr-Wgt Ratio (Torque/Wgt) | 260 ft-lbs/lbs |
| Product Height | 7.2'' / 183mm |
| Product Length | 9.6'' / 244mm |
| Product Weight | 5lbs / 2.27kg |
| Product Width | 2.9'' / 74mm |
| Quiet Tool | Yes |
| Rec. Forward Torque Range | 870 ft-lbs / 10444 in-lbs / 1180 Nm |
| Retainer Type | Friction Ring |
| Side to Center Distance(in) | 1.45'' / 37mm |
| Speed Setting | Variable Speed |
| Standards/Certifications | CE |
| Tool Type | Full-size |
| UPC | 663023120010 |
| Vanes | 7 |
| Vibration Level (m/s2) | 7.7m/s2 |
| Warranty | 2-year |
